CONFIGURATION
Through the Web Browser you can configure the Switch functions such as
VLAN, Trunking, QoS… etc.
With the attached Web Management Utility, you can easily discover all Web
Managed Switches, assign the IP Address, change the password, and upgrade
with new firmware.
Installing the Web Management Utility
The following provides instructions guiding you through the installations of
the Web Management utility.
1. Insert the Utility CD in the CD-ROM Drive.
2. From the Start menu on the Windows desktop, choose Run.
3. In the Run dialog box, type D:\Web Management Utility\setup.exe (D:\
depends where your CD-ROM drive is located) and click OK.
4. Follow the on-screen instructions to install the utility.
5. Upon completion, go to Program Files -> web_management_utility and
execute the Web Management utility. (Figure 7.)
Figure 7. Web Management Utility
The Web Management Utility was divided into four parts, Discovery List,
Monitor List, Device Setting, and Toolbar function, for detailed instructions,
follow the section below.
