DB178RMP / DB179RMP / DB179RGMP
FM tuner
Frequency Range: 87.5 MHz to 108 MHz
Usable Sensitivity: 11 dBf
50 dB Quieting Sensitivity: 17 dBf
Alternate Channel Selectivity: 75 dB
Stereo Separation
(
1 kHz
)
: 35 dB
Frequency Response
(
±
3 dB
)
: 30 Hz to 15 kHz
General
Power Supply Voltage:
14.4 V DC
(
10.8 V to 15.6 V allowable
)
, nega-
tive ground
Current Consumption: Less than 15 A
Speaker Impedance: 4 Ω
(
4 Ω to 8 Ω allowable
)
Weight: 2.42 lb.
(
1.1 kg
)
Dimensions:
178 mm Width X 50 mm Height X 152 mm
Depth
9. SPECIFICATIONS
AM tuner
Frequency Range:
MW 531 kHz to 1602 kHz
LW 153 kHz to 279 kHz
Usable Sensitivity: 25 μV
CD player
System: Compact disc audio system
Usable Discs: Compact disc
Frequency Response: 10 Hz to 20 kHz
(
±
3 dB
)
Signal-to-Noise Ratio: 85 dB
(
1 kHz
)
IHF-A
Dynamic Range: 87 dB
(
1 kHz
)
Harmonic Distortion: 0.01%
Notes:
• Specifications comply with JEITA Standards.
• Specifications and design are subject to change
without notice for further improvement.
• Please make sure when connecting external power
amplifier, that you properly, to the car chassis,
ground the amplifier.
• If this is not done, severe damage to the source
unit may happen.
Audio
Maximum Power Output: 200 W
(
50 W X 4 ch
)
Power Output: 4 X 25 W
(
DIN 45324,
+
B
=
14.4 V
)
Bass Control Action
(
100 Hz
)
: ±14 dB
Treble Control Action
(
10 kHz
)
: ±14 dB
Line Output
(
with A/C 1 kHz, 10 k
Ω
)
: 1.8 V
