REV 92500-20140519 22
92500 ENGLISH
Parts List
# Part Number Description Qty
1
PMJ22M-02-00 Beam 1
2
GB/T 5782-2000
(M12×75)
Bolt M12×75 (12.9) 1
3
PMJ22J-04-00 Wedge Slide 1
4
GB/T 95-2000 (Ø12) Washer ø12 5
5
GB/T 889.1-2000 (M12) Lock Nut M12 6
6
PMJ22G-51 Control Valve "IN" Connector 1
7
PMJ22J-12A Control Valve 1
8
PMJ22J-19 Plate 1
9
GB/T 818-2000
(M8x12)
Bolt M8×12 2
10
GB/T 859-1987 (Ø8) Washer ø8 3
11
PMJ22G-49 Control Valve "OUT" Connector 2
12
JB/T 8870-1999 (d25) Clamp d25 2
13
PMJ7-15 Right Angle Joiner II 2
14
PMJ7-22 Through Joiner II 1
15
PMJ22M-21 Hydraulic Hose (Valve-Cylinder) 1
16
PMJ22M-08-00-R Cylinder (Red) 1
17
PMJ22M-13 Wedge Pin 1
18
GJY12-3 R-Pin 3
19
PMJ22G-15 Hydraulic Hose (Valve-Oil Tank) 1
20
PMJ22M-03-00 Base Tube 1
21
PMJ22J-10 Pin 1
22
PMJ22G-30 R-Pin 2
23
PMJ22G-40 2 in. Coupler 1
24
GB/T 5782-2000
(M12×80)
Bolt M12×80 2
25
GB/T 5782-2000
(M12×90)
Bolt M12×90 1
26
GB/T 97.2-1985 (Ø12) Washer ø12 4
27
PMJ22G-41 Safety Chain With Hook 2
28
PMJ22J-07-00 Front Support Leg 1
29
PMJ22J-18 Hydraulic Hose (Valve-Pump) 1
30
GB/T 3452.1-92
(Ø10×2.65)
O Ring 10×2.65 1
31
PMJ22G-21 Outlet Connector Of Pump 1
32
PMJ22J-14 Gear Pump 1
33
JB/T 8870-1999 (d40) Clamp d40 2
34
PMJ22G-17 Oil Pipe 1
35
GB/T 5783-2000
(M8×30)
Bolt M8×30 4
36
GB/T 95-2000 (Ø8) Washer ø8 16
37
GB/T 93-1987 (Ø8) Lock Washer ø8 16
# Part Number Description Qty
38
GB/T 6170-2000 (M8) Nut M8 10
39
GB/T 77-2000 (M6×10) Screw M6×10 1
40
PMJ22G-26 Gear Pump Connector 1
41
ASME B18.2.1 1996 Bolt 5/16 in. - 24×1in. 4
42
PMJ22G-29 Engine Bushing 1
43
27.101.1 Engine (Black) 1
44
GB/T 1096-1979 (5x5) Flat Key 5x5 1
45
PMJ22G-28 Engine Connector 1
46
PMJ22G-27 Gear Pump Stand 1
47
PMJ22G-32 Connector Cover 1
48
GB/T 845C-1985 Tapping Screw 4
49
GB/T 848-1985 (Ø4) Lock Washer ø4 4
50
GB/T 859-1987 (Ø4) Washer ø4 4
51
GB/T 1099-1979 (3x3) Flat Key 3x3 1
52
PMJ22Q-22 Filter Connector 1
53
PMJ22Q-20 Internal Oil Filter 1
54
PMJ22G-19 Oil Plug 1
55
GB/T 5782-2000
(M8×45)
Bolt M8×45 4
56
PMJ22J-05-02 Axle Cap 2
57
GB/T 9459-1988
(M20x1.5)
Slotted Nut M20×1.5 2
58
L44634 LYC DS Tapered Bearing 4
59
PMJ22J-05-03-R Wheel (Red) 2
60
PMJ22J-05-01 Cased Seal 2
61
GB/T 91-2000 (4×32) Cotter Pin 4×32 2
62
PMJ22M-01-00 Oil Tank 1
63
PMJ22G-12 Hinge Pin 1
64
GB/T 5782-2000
(M12×85)
Bolt M12×85 2
65
PMJ22G-18 Screw NPT 1 in. 1
66
GB 1160.2-89 Oil Scale 1
67
PMJ22J-15 Pin 1
68
PMJ22G-38 Big Tension Spring 1
69
PMJ22G-53 Small Tension Spring 1
70
GB/T 798-1988
(M8x35)
Swing Bolt M8×35 1
71
PMJ30F-01-R Log Catcher (Red) 2
72
GB/T 95-2000 (Ø10) Washer ø10 8
73
GB/T 93-1987 (Ø10) Lock Washer ø10 8
74
GB/T 5781-2000
(M10x15)
Bolt M10×15 8
