6. Position the Bearing squarely on the Axle with smaller diameter
going on first. Use the 1” Pipe and Hammer to tap the Bearing
onto the Axle.
5. Position the Wheel on the Axle.
The inside hub should seat against the inside Bearing .
7. Install the Castle Nut and tighten to fully seat the Bearing.
Continue with assembly according to the Operator manual.
92301 - Wheel Bearing
Instalaltion, 9-14-2012
