REV 92251-1-20131206 24
92251-1 ENGLISH
Engine Parts List
# Part Number Description Qty
1
B057890006001670X Bolt M6×16 4
2
11221-LC90-0500 Valve Cover 1
3
12104-KB01-0200 Breather Hose Assembly 1
4
90229-KB01-0400 Valve Cover Gasket 1
5
15400-LC90-0001 Rocker Arm Assembly 2
6
15414-KB01-0000 Nut,Pivot Locking 2
7
15403-KB01-0000 Adjusting Nut,Valve 2
8
15401-LC90-0001 Rocker Arm 2
9
15415-KB01-0000 Bolt,Pivot 2
10
15406-KB01-0000 Push Rod Guide 1
11
15711-KB01-0000 Valve Spring Retainer (Intake) 1
12
15713-KB01-0000 Exhaust Lash Cap 1
13
15712-KB01-0000 Valve Spring Retainer (Exhaust) 1
14
15703-KB01-0000 Valve Spring 2
15
1572B-JD45-0000 Valve Seal (Intake) 1
16
1122R-LC90-0000 Bolt M8× 60 4
17
1122B-LC90-0300 Cylinder Head 1
18
81300-KB01-0400 Spark Plug(F6RTC) 1
19
91138-KB03-0000 Stud M8× 34 2
20
18066-LC90-0000 Exhaust Pipe Gasket 1
21
B061700008000060X Nut,M8 2
22
B0578900060010702 Bolt M6×10 2
23
18000-LZ4A-0000 Muffler Assembly 1
24
18016-LZ4A-0000 Exhaust Pipe Guard 1
25
B057890006000870H Bolt M6× 8 3
26
91127-KB01-0000 Stud M6×113 2
27
17107-LC90-0100 Carburetor Insulator Gasket 1
28
17112-KB01-0000 Carburetor Insulator 1
29
17182-KB01-0300 Carburetor Gasket 1
30
17100-LC90-2900 Carburetor Assembly 1
31
17113-KB01-0000 Carburetor Gasket Plate 1
32
16100-LZ4A-0100 Air Cleaner Assembly 1
33
16180-LZ4A-0100 Air Cleaner Housing 1
34
16104-IC77-0000 Sponge Filter 1
35
16101-IC77-0000 Air Cleaner Filter Assembly 1
36
16105-LZ4A-0000 Air Cleaner Cover 1
37
B06177P106000090X Nut M6 2
38
9022B-LC90-0200 Gasket,Cylinder Head 1
39
91521-10001600000 Dowel Pin Ø10×16 2
40
15321-LC90-0000 Push Rod 2
41
15702-LC90-0000 Exhaust Valve 1
42
15701-KC67-0000 Intake Valve 1
43
15002-LC90-0000 Tappet 2
44
1310A-LZ4A-0000 Piston Ring Set 1
45
13103-LZ4A-0000 1St Piston Ring 1
46
13104-LZ4A-0000 2Nd Piston Ring 1
47
13120-LZ4A-0000 Oil Ring 1
48
13105-KB01-0000 Piston Pin Snap Ring 2
49
13101-LC90-0100 Piston 1
50
13102-LC90-0000 Piston Pin 1
51
B057890006001270X Bolt M6×12 8
52
19113-Z6H-0000 Air Shield 1
53
13220-LC90-0000 Connecting Rod Assembly 1
54
24605-LC90-0000 Governor Arm Shaft 1
55
90101-10052000190 Washer Ø5.2×1.9 1
56
T1105006001100400 Governor Seal 1
57
24606-KB01-0000 Cotter Pin 1
58
15100-LC90-0000 Camshaft Assembly 1
59
92102-00000006205 Radial Ball Bearing,6205 2
60
91601-IB84-0000 Woodruff Key 1
61
13230-LC90-1400 Crankshaft Assembly 1
62
24620-LC90-0200 Governor Gear/Shaft Assembly 1
63
91521-07001400000 Dowel Pin Ø7×14 1
64
91521-09001400000 Dowel Pin Ø9×14 1
65
90208-LC90-0100 Crankcase Cover Gasket 1
66
12301-LC90-0002 Crankcase Cover 1
67
T1107025004125600 Oil Seal,Ø25×Ø41.25×6 1
# Part Number Description Qty
68
14311-LC90-0000CD Dipstick Assembly 1
69
B057890008003270X Bolt M8× 32 7
70
12007-LG10-0700 Crankcase 1
71
91302-91001516000 Washer 2
72
91103-KB01-0000 Oil Drain Plug 2
73
T1105025004125600 Oil Seal Ø25×Ø41.25×6 1
74
81200-LD29-0200 Ignition Coil Assembly 1
75
B057890006002570X Bolt M6× 25 2
76
82150-LC90-1400 Flywheel 1
77
19102-KB01-0100 Cooling Fan 1
78
21520-KB01-0700 Starter Cup 1
79
B06177F014000090X Nut,Special,M14×1.5 1
80
21500-LZ4A-0600CD Recoil Starter 1
81
21530-Z6H-0200CD Blower Housing 1
82
B000950006000000X Gasket Ø6 3
83
B16674A006001070X Bolt M6×10 3
84
21510-LC90-14006X Recoil Starter 1
85
21521-KB01-0000 Alignment Bolt 1
86
21518-KB01-0000 Spring 1
87
21513-KB01-0000 Guide Plate 1
88
21512-KB01-0000 Starter Pawl 2
89
21515-KB01-0000 Return Spring, Starter Pawl 2
90
21511-KB01-0000 Starter Reel 1
91
21517-KB01-0100 Starter Rope 1
92
21516-IB84-0000 Starter Handle 1
93
21514-LC90-0100 Recoil Spring 1
94
21519-LC90-07006X Blower Housing 1
95
72380-IB84-0200 Ignition Switch 1
96
24610-KB01-2300 Primer Bracket 1
97
B057870006001270X Bolt M6×12 2
98
24602-LC90-1100 Governor Spring 1
99
24603-KB01-0300 Throttle Linkage Spring 1
100
24604-KB01-0000 Throttle Linkage 1
101
24640-LC90-0000 Governor Arm Assembly 1
102
24607-LC90-0000 Governor Arm 1
103
B06177P106000090X Nut M6 1
104
91121-1060-02120X Governor Arm Bolt 1
105
87400-LC90-0200 Oil Sensor 1
106
T2999404001000108 Fuel Hose 1
107
17020-KB01-0400 Fuel Hose Clamp Ø9.5×8 2
108
10061-LZ4A-0000 Wire Clamp 1
109
14304-LZ4A-0100 Dipstick Decoration Cover 1
110
24681-LC90-0000 Bolt 2
111
14301-LC90-0500MV Dipstick Assembly 1
112
90101-10155000150 Oil Filler Tube O-Ring 2
113
14312-LC90-0100MV Oil Filler Tube 1
114
90101-30210000277 Oil Filler Tube O-Ring 1
115
14312-LC90-0100MV Oil Filler Plug 1
116
B057870006001670X Flange Bolt M6×16 2
117
61120-JC79-0700 Cap Componet,Fuel Tank 1
118
61100-LZ4A-04006X Fuel Tank Assembly 1
119
61137-LC90-0300 Fuel Filter 1
120
61195-IB71-1300 Fuel Tank Nipple 1
121
B061770106000090X Nut,M6 2
122
B057890006002070X Bolt M6×20 1
123
87420-KB01-0000 Isolators 1
124
10008-9999-0100 Line Clamp 1
125
19112-LC90-0100 Blower Housing Shield 1
126
6114M-LC90-0000 Check Valve 1
127
61182-QD03-0000 Rubber Pad 2
128
61101-LZ4A-0100 Fuel Hose 1
129
13215-KB01-0000 Connecting Rod Bolt 2
