SKU 94667 For technical questions, please call 1-800-444-3353.
PAGE 2
SPECIFICATIONS TABLE
Maximum Air Pressure 115 PSI
Air Tank Capacity 21 Gallons
Air Flow Capacity
4.9 SCFM at 90 PSI
7 SCFM at 40 PSI
Motor
3 HP Working / 5 HP Peak
120 Volt / 60 Hz / 12 A / 1-Phase
Required Circuit Minimum 20 Amp *Dedicated
Pump Stage Single
Air Outlet Size 1/4” - 18 NPT
Accessories Air Intake Filter; Air Hose Coupler
*A dedicated circuit is used only for a single load, for this compressor. Other loads on the circuit must be
disconnected or turned off when the compressor is plugged in.
SAVE THIS MANUAL
You will need this manual for the safety warnings and precautions, assembly, operating,
inspection, maintenance and cleaning procedures, parts list and assembly diagram.
Keep your invoice with this manual. Write the invoice number on the inside of the front
cover. Keep this manual and invoice in a safe and dry place for future reference.
GENERAL SAFETY WARNINGS AND PRECAUTIONS
1. KEEP WORK AREA CLEAN AND DRY. Cluttered, damp, or wet work areas
invite injuries.
2. KEEP CHILDREN AWAY FROM WORK AREA. Do not allow children to handle
this product.
3. KEEP IDLE EQUIPMENT. When not in use, tools and equipment should be kept
in a dry location to inhibit rust. Always lock up tools and equipment, and keep out
of reach of children.
4. DO NOT USE THIS PRODUCT IF UNDER THE INFLUENCE OF ALCOHOL OR
DRUGS. Read warning labels on prescriptions to determine if your judgement or
reexes are impaired while taking drugs. If there is any doubt, do not attempt to
use this product.
5. USE EYE AND HAND PROTECTION. Wear ANSI-approved safety impact
goggles and heavy-duty work gloves when using this product. ANSI-approved
safety impact eyeglasses and heavy-duty work gloves are available from Harbor
Freight Tools.
6. DRESS SAFELY. Do not wear loose clothing or jewelry, as they can become
caught in moving parts. Wear a protective hair covering to prevent long hair from
becoming caught in moving parts. If wearing a long-sleeve shirt, roll sleeves up
above elbows.
REV 06l; 07c; 09c, 10a
#233060
