SKU 44811 Page 5
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS DIAGRAM
IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER NOR
DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE
BUYER THAT HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT OR
THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT. IN FACT,
THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY STATES THAT ALL REPAIRS
AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND
LICENSED TECHNICIANS AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK
AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT
OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION
OF REPLACEMENT PARTS THERETO.
NOTE: Some parts are listed and shown for illustration purposes only and are not
available individually as replacement parts.
Maintenance
1. Clean the unit as needed. Make sure the face of the Ram (#6) and the
Base Spacer (#8) are clean and free of oil, grease, dirt, and debris.
2. Before each use, bleedthe Pump (#9) of air.
A. Close the Release Valve Knob (#27A), and pump the Handle (#2A)
several times.
B. Hold the Handle (#2A) down, and slowly open the Release Valve Knob
(#27A).
C. Repeat if necessary.
No. Description Qty.
1 Frame Assembly 1
2 10 Ton Ram 1
3 Nut M57 x 1.75 1
4 Short Tube 1
5 Chord Axis 1
6 Ram 1
7 Long Tube 1
8 Base Spacer 2
9Pump 1
Recommended Uses:
1. Electric Motor and Armature repair.
2. Installation and removal of smaller pressure fitted parts (ie: gears, bearings).
3. Bending or straightening metal.
