Chapter 2 Installing Integration Engine 29
Gathering information
Database adapter prerequisites
Review the prerequisites in Table 2-3 for database adapters.
Gathering information
The worksheet in Table 2-4 includes a list of selections for which you are prompted
during installation. It is organized by dialog boxes, which are placed in the order
in which they are displayed during the installation. Complete the worksheet
before starting the installation.
Table 2-4: Integration Engine installer worksheet
Table 2-3: Database adapter prerequisites
Integration Engine
component
Requirements Check
DB2 adapter
DB2 8.2 client software installed on the
computer where the DB2 adapter is installed.
The client must be configured to point to your
DB2 database.
Oracle adapter Oracle 9i (Release 2) or Oracle 10g (Release 2) client
software installed on the computer where the Oracle
adapter is installed. The client must be configured to
point to your Oracle database.
SQL Server adapter SQL Server 2000 or 2005 (Standard or Enterprise)
client software installed on the computer where the
SQL Server Adapter is installed. The client must be
configured to point to your SQL Server database.
Entry or
selection
Description Enter your information
Action Request System server information window
AR server
name
Name of your AR System server.
AR server port
number
Number of the port you want to
use. To locate the port number on
UNIX, go to
<ar_install_dir>/
conf/ar.conf
and find the key
name “TCD-Specific Port.”
To find the port number on
Windows, go to
<ar_install_dir>\CONF\ar.cfg
and find “TCD-Specific-Port.”
If your AR System server uses
portmapper, use the default value.
AR server
Administrator
User name of the AR System
administrator.
