VC812 User Manual
24
Specifications
Function VC812
Connectors
Input HDMI In
1 x HDMI Type A female
Output Video Out
1 x HDB-15 female (Black)
Digital Coaxial Audio
1 x RCA female (Yellow)
Analog Stereo Audio
1 x 3.5 mm stereo jack
Power Jack 1 x DC jack
Switches Down 1 x Pushbutton
Up 1 x Pushbutton
Menu 1 x Pushbutton
Firmware Upgrade 1 x Dip switch
LEDs Signal 1 (Green)
Power 1 (Red)
Video 1080p; 1920 x 1200
Power Consumption DC 5V, 10 W
Environment Operation Temperature 0 - 40°C
Storage Temperature -20°C - 60°C
Humidity 20 – 90% RH, Non-condensing
Physical
Properties
Housing Metal
Weight 290g
Dimension (L x W x H) 11.00 x 8.30 x 2.80 cm
Limited Warranty
IN NO EVENT SHALL THE DIRECT VENDOR'S LIABILITY EXCEED THE PRICE PAID
FOR THE PRODUCT FROM DIRECT, INDIRECT, SPECIAL, INCIDENTAL, OR
CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THE PRODUCT, DISK,
OR ITS DOCUMENTATION.
The direct vendor makes no warranty or representation, expressed, implied, or statutory with
respect to the contents or use of this documentation, and especially disclaims its quality,
performance, merchantability, or fitness for any particular purpose.
The direct vendor also reserves the right to revise or update the device or
documentation without obligation to notify any individual or entity of such
revisions, or update. For further inquiries, please contact your direct vendor.
