Section 4, User Interface Guide ATLAS 550 System Manual
300 © 2002 ADTRAN, Inc. 61200305L1-1F
DIAL PLAN (DUAL NX56/64 MODULE)
DIAL PLAN (V35NX) > USER TERM
Write security: 3; Read security: 5
This menu allows the user to define option parameters for ports configured for V.35 connections.
DIAL PLAN (V35NX) > USER TERM > IFCE CONFIG
Write security: 3; Read security: 5
Specifies the configuration parameters for the endpoint.
DIAL PLAN (V35NX) > USER TERM > IFCE CONFIG > PORTS AVAILABLE
Write security: 3; Read security: 5
Indicates which ports of the selected Dual Nx 56/64 Option Module have been defined in this switched
endpoint (indicated by “!”), in another switched endpoint (indicated by “s”), or in a
DEDICATED MAP
(indicated by “n”). This field is read-only. The following characters may display in this field:
DIAL PLAN (V35NX) > USER TERM > IFCE CONFIG > NUMBER OF PORTS
Write security: 3; Read security: 5
Specifies the number of V.35 ports ATLAS 550 uses for this endpoint.
DIAL PLAN (V35NX) > USER TERM > IFCE CONFIG > NUMBER TO DIAL
Write security: 3; Read security: 5
Specifies the number to dial on an outgoing call.
DIAL PLAN (V35NX) > USER TERM > IFCE CONFIG > CALL TYPE
Write security: 3; Read security: 5
Configures the call type (either 56K or 64K) used for outgoing calls from this endpoint.
DIAL PLAN (V35NX) > USER TERM > IFCE CONFIG > DIAL CALL AS
Write security: 3; Read security: 5
Allows the outgoing call to be treated as the selected call type. Options include DIGITAL (for 56K or 64K
0-4 This port is available.
* This port is requesting this port for this connection, but the port is not
yet activated.
! This port is used by this endpoint.
S This port is used elsewhere in the switched DIAL PLAN.
S This port is in the switched dial plan and conflicts with this endpoint.
N This port is used in one or more DEDICATED MAPS.
N This port is in one or more
DEDICATED MAPS, and conflicts with this
endpoint.
