Specifications
i
General
Chipset RTL8722, RLT 825, CMI8769
Standard IEEE 802.11b, Wi-Fi compliant/IEEE 802.11g standard
Flash Memory 2 MByte
SDRAM
16 MByte
Interfaces
1x 3.5mm mini-Audio jack ;
1* SPDIF(Optical out);
1* Power Jack Power for DC 9V / 700 mA; AC Adapter 100V~240V;
1* Antenna SMA connector;
1* Reset button; 1* LAN
LED Indicator (5 LEDs)
Power LED (power up) Green
Wireless Link/actGreen
WAN Link/ActGreen
StatusGreen
Audio Link: Blue
Power Requirement 9V, 700mA (DC)
Physical Specifications
WeightTBD
141mm(W)*100mm(D)*27mm(H)
EMC Certification TBD
Supported OS
Windows 2000/XP
Wireless
Antenna Single Detachable Dipole Antenna
Frequency Range 2.412GHz-2.4835GHz
Number of Selectable
Channels
USA, Canada: 11 channels
Europe: 13 channels
Japan: 14 channels
Modulation Technology
802.11b: Direct Sequence Spread Spectrum (PBCC, CCK, DQPSK, DBPSK)
802.11g: Orthogonal frequency division multiplexing
