LA SERIES - TECHNICAL SPECIFICATIONS
MODEL
Type of Speaker
HF drive unit
HF driver protection
Power Handling
RMS/Music
Nominal Impedance
Sensitivity
SPL (peak)
Frequency Response
Power Amplifier
Crossover point
Weight
Dispersion
Input connector
Dimensions (mm & ins)
H x W x D
LA-15
15” Two way full range
1” Diaphragm dynamic
Protection lamp
250W continuous
500W Program
8Ω
100dB
130dB
45Hz-20kHz
N/A
2.3kHz
23.75 Kg / 52.3 lbs
60 x 40
2 X Speakon™ &
2 x 1/4 Jack
480 x 700 x 380mm
18.9” x 27.6” x 15”
LA-15SUB
15” Sub
--
--
250W continuous
500W Program
8 Ω
98dB
128dB
30Hz- 150kHz
N/A
150Hz
26.5 Kg / 58.4 lbs
N/A
2 X Speakon™ &
2 x 1/4 Jack
480 x 700 x 380mm
18.9” x 27.6” x 15”
DISCOTHEQUES
AIRPORTS
PLACES OF WORSHIP
RETAIL PREMISES
SHOPPING CENTRES
RESTAURANTS
PUBLIC HOUSES
SPORTS COMPLEXES
RAILWAY STATIONS
HOTELS
IAGHouse, Sovereign Court, Ermine Business Park, Huntingdon, Cambridgeshire, PE29 6XU
Tel: 0845 458 0011 / +44 (0) 1480 447700 Fax: +44 (0) 1480 431767
www.wharfedalepro.com
The infomation in this brochure is subject to change without notice. All rights reserved © 2004 Wharfedale Pro
Wharfedale Pro is a member of the International Audio Group
LA-15P
LA-15P
15” two way full range
1” Diaphragm dynamic
Protection lamp
250W continuous
500W Program
8 Ω
100dB
129dB
45Hz- 20kHz
200W
2.3kHz
35 kg / 77.1 lbs
60 x 40
2 x XLR/1/4” jack
combi
480 x 700 x 380
18.9” x 27.6” x 15”
LA-15PB
15” Sub
--
--
250W continuous
500W Program
8 Ω
98dB
125dB
30Hz- 150Hz
200W
150Hz
33.25kg / 73.3 lbs
N/A
2 x XLR/1/4” jack
combi
480 x 700 x 380
18.9” x 27.6” x 15”
Frequency
LA-15PB Low Pass 100
Band Pass 30Hz-150Hz
Frequency
LA-15P Low Pass 2300
High Pass 2300
