WD TV Live Streaming Media Player
User Manual
FEATURES AND FUNCTIONS – 9
Connections
Item Component Description
1 USB port 1 Supports connection of compatible removable storage
devices, portable media players, and digital cameras with
USB connectors.
2 Reset button
(bottom of device)
Press for one second to reset to factory defaults (see “Device
Reset” on page 199). Press and hold 10 seconds to toggle
between NTSC and PAL. Use a fine-tipped stylus or the
unfolded end of a paperclip to press the reset switch.
3 Power jack Connects the power cable.
4 S/PDIF (optical)
audio port
Connects to your AV receiver (S/PDIF cable sold separately).
5 Ethernet port Supports LAN connection for wired Internet access.
6 HDMI port Connects to your TV’s HDMI port (HDMI cable sold
separately).
7 USB port 2 The same function as USB port 1.
8 Composite jack Connect to your TV’s analog video and audio jacks.
1
2
3 4 5
6
7 8
