VCC-5 Operation Manual
7
Vandersteen Audio
PACKING INSTRUCTIONS
To prevent physical or cosmetic damage always pack the
VCC-5 in its original box prior to transportation or shipment.
Please follow these instructions when packing the VCC-5.
1. Place the speaker on one side on a padded surface.
2. Pull the plastic bag over the speaker
3. Carefully turn the speaker right side up and close bag.
4. Place one tray, foam side down into the box.
5. Place the speaker into bottom tray.
6. Carefully place top tray, foam side up over the speaker.
7. Close the box flaps and seal with tape.
MAINTENANCE
The appearance of the VCC-5 can be preserved by ob-
serving a few precautions and performing some simple main-
tenance. The grille cloth on the VCC-5 can be vacuumed
using a brush attachment that will not snag the cloth. The
top should be treated as a piece of fine furniture. The wood
veneers are oiled at the factory and can be maintained with
an occasional light application of Pledge or a similar prod-
uct.
Care should be taken that objects that could mar the finish
are not placed on top of the speaker. Do not expose the
speaker to excessive heat, sunlight or moisture, which can
damage the fit and finish of the veneer.
SPECIFICATIONS
Driver: Magnetically shielded triaxial design com-
bining (2) 6
1/2” die-cast basket polycone
woofers, (1) 6
1/2” die-cast polycone mid-
range and a proprietary 1” critically-
damped, alloy dome tweeter.
Crossover: 150, 3500Hz. First order, 6dB per octave.
Phase: All drivers in positive absolute phase.
Enclosure: 1-11/2” think constrained-layer-dampened
MDF.
Impedance: 4 ohms nominal.
Sensitivity: 86dB at 1 meter with a 2.83 volt input.
Response: 55Hz to 21,000Hz ± 3dB Proximity Off.
Amplification: 100 to 200 watts per channel .
Size: 24 1/4” wide, 9 3/4” high, 17 1/2” deep.
Weight: 68# net, 78# gross.
Specifications and design are subject to change without notice due
to our continuous research and development program
TOP TRAY
PLASTIC BAG
VCC-5
VANDERSTEEN AUDIO
116 W. FOURTH STREET HANFORD, CA, 93230
↑ ↑
MODEL VCC-5 CENTER
FRAGILE
UP UP
DIMENSIONAL PURITY
VANDERSTEEN AUDIO
116 WEST FOURTH STREET
HANFORD, CA 93230
(559) 582-0324
www.vandersteen.com
BOTTOM TRAY
