10
GB
Adjusting the sound
Slight adjustments to the system can enhance
your sound enjoyment.
Adjusting the
subwoofer
(SA-VE705 and SA-VE702 only)
Operation panel on the subwoofer
LEVEL MODE
LEVEL
MODE
MIN
ON/
STANDBY
MAX
MOVIE
MUSIC
POWER
1 Set MODE according to the program
source as follows:
Source MODE
DVD, LD, video cassette MOVIE
or other video source
MD, CD, cassette tape MUSIC
or other audio source
2 Rotate LEVEL to adjust the volume.
Set the volume level to suit the program
source.
Notes
•Some amplifier functions for enhancing the sound
may cause distortion in the subwoofer. If such
distortion occurs, turn off those functions.
•To enjoy high-quality sound, do not turn the
subwoofer volume too high.
•To increase the bass sound from the subwoofer,
connect the system using “Hookup B” (see
page 5).
Setting your amplifier
for Dolby Digital*
If your amplifier is connected internally or
externally with a Dolby Digital processor,
you should use the some setup menus in the
amplifier to specify the parameters of your
speaker system.
See the table below for the proper settings.
For details on the setting procedure, refer to
the manual that was provided with your
amplifier.
* To enjoy Dolby Digital, five speakers and one
subwoofer must be provided.
When “Hookup A” is used
(Speaker setup menu)
For Set to
Front speakers SMALL
Center speaker SMALL
Rear speakers SMALL
Subwoofer ON (or YES)
(Other setup menu)
Menu Set to
LFE* MIX –10 dB
BASS BOOST** ON
* Low Frequency Effect
**A function that reinforces the bass sound
When “Hookup B” is used
(Speaker setup menu)
For Set to
Front speakers LARGE
Center speaker SMALL
Rear speakers SMALL
Subwoofer OFF (or NO)
(Other setup menu)
Menu Set to
LFE MIX –10 dB
BASS BOOST ON
