Outlaw Audio
Owner’s Manual
Specifications
Model LFM-1 EX Specifications
Driver Type Down Firing, 12" Long-throw Woofer
Ports Dual
Amplifier Power Rating 350WRMS; 1300W peak
Frequency Response 16Hz -180Hz ± 2 dB Maximum Extension
22Hz -180Hz ± 2 dB Maximum Output
Crossover Type Linkwitz-Reilly 4th Order Low Pass Network
Crossover Frequency 40Hz to 180Hz and Bypass
Phase 0 to 180 Degrees
SPL
118dB
(subject to placement and room gain)
Dimensions (HxWxD) 21.5” x 17.0” x 24.0”
Weight 80 lbs
Model LFM-1 Plus Specifications
Driver Type Down Firing, 12" Long-throw Woofer
Ports Dual
Amplifier Power Rating 350WRMS; 1300W peak
Frequency Response 18Hz -180Hz ± 2 dB Maximum Extension
25Hz -180Hz ± 2 dB Maximum Output
Crossover Type Linkwitz-Reilly 4th Order Low Pass Network
Crossover Frequency 40Hz to 180Hz and Bypass
Phase 0 to 180 Degrees
SPL
115dB
(subject to placement and room gain)
Dimensions (HxWxD) 21.75” x 15.0” x 22.0”
Weight 58 lbs
