Mirage Loudspeakers OM-6 Portable Speaker User Manual


  Open as PDF
of 22

OM-14
Vented Omnipolar™
2- Way, 4-Driver System
38Hz - 22KHz
2 - 3/4” (19mm) PMD™
Pure Metal Dome™
2 - 5-1/2” (14cm) w.
I.M. Polypropylene Cones &
I.M. Copolymer Baskets
with Butyl Surrounds
N/A
N/A
N/A
N/A
2.0KHz
90dB
8-ohms Compatible
30 - 150-watts
RMS/ Channel
N/A
Bi-Amp/Bi-Wire High Level
(Gold Plated)
34-5/8 x 9 x 10-3/8
88.1 x 22.9 x 26.2
High Gloss Black Lacquer
with Acoustically Transparent
Grille Cloth
35
15.9
N/A
OM-C2
2-Way, 5-Driver
Dual-Chamber Omnipolar™
38 - 22KHz
2 - 1” (25mm) PTH™
Pure Titanium Hybrid™
2 - 5-1/2” (14cm) w.
I.M. Polypropylene Cones &
I.M. Copolymer Baskets
with Butyl Surrounds
N/A
N/A
N/A
1 - 5-1/2” (14cm)
1.9KHz
91dB
8-ohms Compatible
30 - 175-watts
RMS/ Channel
N/A
Bi-Amp/Bi-Wire High Level
(Gold Plated)
7-3/8 x 24-5/8 x 12-1/8
18.6 x 62.7 x 30.9
Matte Black with High Gloss
Black Lacquer End Caps &
Black Grille Cloth
30
13.6
N/A
MODEL
SYSTEM TYPE:
FREQUENCY RESPONSE:
DRIVERS: Tweeter
Bass/Mid
Range
INTERNAL SUBWOOFER
AMPLIFIER TYPE:
POWER OUTPUT:
SUBWOOFER:
PASSIVE RADIATOR:
CROSSOVER POINTS:
ROOM EFFICIENCY:
IMPEDANCE:
RECOMMENDED
AMPLIFIER POWER:
LOW FREQUENCY EQ:
INPUTS:
DIMENSIONS: inches
h x w x d cm
FINISH:
WEIGHT: lb
kg
SUPPLY VOLTAGE:
OM-6
Omnipolar™ Radiator with
Integrated Powered
Subwoofer
18Hz - 22KHz
2 - 1” (25mm) PTH™
Pure Titanium Hybrid™
2 - 5-1/2” (14cm) w.
I.M. Polypropylene Cones &
I.M. Copolymer Baskets
with Butyl Surrounds
High Current MOSFET w.
Isolated Power Supply Module
150-watts, 600-watts
Instantaneous Peak
2 - 8” (20cm) Long
Throw Polypropylene
N/A
80Hz, 1.9KHz
91dB
6-ohms Nominal,
4-ohms Minimum
30 - 200-watts
RMS/ Channel
Cont.Variable -3dB @ 20Hz to
+3dB @ 45Hz
Bi-Amp/Bi-Wire High Level
(Gold Plated) &
Low Level RCA
45-1/2 x 9-3/4 x 16-1/2
115.6 x 24.8 x 41.9
High Gloss Black Trim
with Acoustically Transparent
Grille Cloth
61-1/2
27.9
110/120v, 60Hz
220/240v, 50Hz
OM-8
Omnipolar™ Radiator w.
Integrated Powered
Subwoofer
28Hz - 22KHz
2 - 1” (25mm) PTH™
Pure Titanium Hybrid™
2 - 5-1/2” (14cm) w.
I.M. Polypropylene Cones &
I.M. Copolymer Baskets
with Butyl Surrounds
High Current MOSFET with
Isolated Power Supply Module
150-watts, 600-watts
Instantaneous Peak
2 - 6-1/2” (16.5cm) Long
Throw Polypropylene
N/A
100Hz, 1.9KHz
91dB
6-ohms Nominal,
4-ohms Minimum
30 - 200-watts
RMS/ Channel
Cont.Variable -3dB @ 20Hz to
+3dB @ 45Hz
Bi-Amp/Bi-Wire High Level
(Gold Plated)
44-1/4 x 9-3/4 x 16 5/8
112.4 x 24.8 x 42.2
High Gloss Black Trim
with Acoustically Transparent
Grille Cloth
60
27.2
110/120v, 60Hz
220/240v, 50Hz
OM-10
Vented Omnipolar™
2- Way, 4-Driver System
28Hz - 22KHz
2 - 1” (25mm) PTH™
Pure Titanium Hybrid™
2 - 6-1/2” (16.5cm) w.
I.M. Polypropylene Cones &
I.M. Copolymer Baskets
with Butyl Surrounds
N/A
N/A
N/A
N/A
1.9KHz
90dB
6-ohms Nominal,
4-ohms Minimum
30 - 200-watts
RMS/ Channel
N/A
Bi-Amp/Bi-Wire High Level
(Gold Plated)
46-3/8 x 9 x 11-7/8
117.8 x 22.9 x 30.2
High Gloss Black Trim
with Acoustically Transparent
Grille Cloth
39.5
17.9
N/A
OM-12
Vented Omnipolar™
2- Way, 4-Driver System
32Hz - 22KHz
2 - 1” (25mm) PTH™
Pure Titanium Hybrid™
2 - 5-1/2” (14cm) w.
I.M. Polypropylene Cones &
I.M. Copolymer Baskets
with Butyl Surrounds
N/A
N/A
N/A
N/A
2.0KHz
90dB
6-ohms Nominal,
4-ohms Minimum
30 - 150-watts
RMS/ Channel
N/A
Bi-Amp/Bi-Wire High Level
(Gold Plated)
39-7/8 x 9 x 11
101.3 x 22.9 x 27.9
High Gloss Black Trim
with Acoustically Transparent
Grille Cloth
37
16.8
N/A
OM-C3
2-Way, 3-Driver
Shielded Center Channel or
L/C/R
40 - 22KHz
1 - 1” (25mm) PTH™
Pure Titanium Hybrid™
2 - 5-1/2” (14cm) w.
I.M. Polypropylene Cones &
I.M. Copolymer Baskets
with Butyl Surrounds
N/A
N/A
N/A
N/A
1.9KHz
91dB
8-ohms Nominal
30- 175-watts
RMS/ Channel
N/A
High-Level
(Gold Plated)
7 x 21-1/2 x 10-7/8
17.8 x 54.6 x 27.6
Matte Black with
Black Grille Cloth
24 each
10.9 each
N/A
OM-R2
Vented 2-Way Omnipolar™
Hemispherically Radiating Wall-
Mounted Rear/Surround
80Hz - 22KHz
2 - 1” (25mm) PTH™
Pure Titanium Hybrid™
1 - 6-1/2” (16.5cm) w.
I.M. Polypropylene Cones &
I.M. Copolymer Baskets
with Butyl Surrounds
N/A
N/A
N/A
N/A
1.9KHz
90db
8-ohms Nominal
15- 125-watts
RMS/ Channel
N/A
High-Level
(Gold Plated)
8-5/8 x 11-3/4 x 5-1/4
21.9 x 29.8 x 13.3
Matte Black or White
with Matching Grilles
10 each
4.5 each
N/A
owners manual OM-Series
SPECIFICATIONS
SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE
