MO-1008 / 4008 / 1016 / 4016 User’s Guide
20 © 2004, Midland Radio Corporation
Press and release this button and use the up and down keys to
change the noise squelch level for the current channel. The
squelch range is 0-16 with 1 being the most sensitive level.
Selecting 0 will disable the noise squelch circuit. Press the
squelch button again to exit squelch level mode.
Talk Around
Press and release this button to shift the radio transmit
frequency to the programmed channel receive frequency. This
allows the radio to communicate directly with other radios, which
normally communicate through a repeater system. Press again
to change back to the programmed transmit frequency.
Tx Power
Press and release this button to toggle the transmit power
between the high and low power levels.
Message Display Quick Reference
Error Codes
Display Description
E1
No response from EEPROM
E2
PLL unlock
E3
EEPROM data error
E4
Radio high temperature
E5
Cloning error
E6
Serial communication error
E7
Low battery voltage
E8
High battery voltage
E9
Password entry error
EA
Incorrect radio model
EE
Radio mode error
