6
POWER SOURCE
AC CONNECTION
Insert the small end of the AC adapter into the POWER IN jack (located on the rear of
the unit). Connect the AC cord to the adapter and connect the other end to a wall outlet
having 120V AC, 60 Hz.
NOTES:
• Only use the supplied AC adapter which has the following specs: DC 12V Z
• The AC adapter supplied with the unit is polarized to help minimize the possibility
of electric shock. If the AC plug does not fit into a nonpolarized AC outlet, do not
file or cut the wide blade. It is the user’s responsibility to have an electrician replace
the obsolete outlet.
• Remove both the DC plug and the AC-IN plug to disconnect the AC adapter when
not using.
• The batteries are automatically disconnected when the AC adapter is used.
BATTERY INSTALLATION
To use this unit with battery power, remove
the battery door on the rear of the unit and
insert eight (8) ‘D’ size batteries following
the illustration.
NOTE: The AC power cord must be
disconnected from the POWER IN jack on
the rear of the unit in order for the unit to
operate on battery power.
+
–
+
–
+
–
+
–
+
–
+
–
+
–
+
–
BATTERY PRECAUTIONS
Follow these precautions when using batteries in this device:
1. Use only the size and type of batteries specified.
2. Be sure to follow the correct polarity when installing the batteries as indicated in the
battery compartment. Reversed batteries may cause damage to the device.
3. Do not mix different types of batteries together (e.g. Alkaline, Rechargeable and Carbon-
zinc) or old batteries with fresh ones.
4. If the device is not to be used for a long period of time, remove the bat
teries to prevent
damage or injury from possible battery leakage.
5. Do not try to recharge batteries not intended to be recharged; they can overheat and
rupture. (Follow battery manufacturer’s directions.)
AC Plug
AC Outlet
