FM Receivers
• Super Quiet™ Technology provides superior audio quality.
• Look&Listen™ LCD.
• 57-programmable channels.
• Adjustable squelch control.
• Selectable audio output.
• Multiple input and output options.
Highlights
• The LA-326 Universal Rack Mounting Kit can
rack mount one or two LR-100 Stationary FM
Receivers (includes security cover).
• Receiver range from LT-700: Line of site, 150 ft
(45.7 m), 72/216MHz.
• Number of simultaneous channels: 6/3,
72/216MHz.
• System audio performance: 63 Hz - 15KHz
frequency response, >80dB SNR and <2% THD.
• Speaker Output: 15/10 wats (peak/RMS) with
4 ohm load.
LR-100-072 - 72MHz
LR-100-216 - 216MHz
Key Speci cations
Con gurations
Accessories
1. Audio Section Audio can be adjusted for volume and quality via trim pots and switches. Listen
exclusive technology delivers low noise performance.
2. Receive Section Use the UP and DOWN buttons to select the transmission channel. The LCD
conveniently shows the selected channel, transmitter output power, lock and programming status.
3. Monitor Section You can listen to the transmitted audio using the monitor jack and volume control.
4. Speaker Volume Adjustable volume control for speaker output.
5. Audio Output Section O ers three di erent output options: unbalanced/phono, balanced male XLR
and Phoenix connector for speaker.
6. Audio Input Section Three di erent audio inputs: RF signal through the antenna, unbalanced/phono
or balanced/female XLR 1/4 inch combo connector.
7. Power Connect a power supply (included) to the back of the unit.
1
6
5
234
7
Listen’s LR-100 Stationary Receiver/Power Ampli er is a
stationary receiver with a built-in power ampli er. When used
with a Listen transmitter, the LR-100 can deliver high quality
audio for use in a variety of locations and applications – most
commonly sound elds. This unit has Listen’s signature
Look&Listen™ LCD Display showing channel, lock, and battery
level. A security cover protects auxiliary and receiver volume
and trim controls. It has an adjustable squelch control, and
balanced or unbalanced speaker wire output options.
Multiple input options give this unit great exibility.
It’s powered by a 16VAC/1000mA power input or 12 VDC
battery. Add an antenna for longer range applications.
