Version 1.2 - 9/23/2008
Page 11 of 25
Display.
The Daylight Saving Time (DST) checkbox on your Wireless Display settings at
www.weatherdirect.com is selected by default because most locations observe
DST. If you are in a location that does not observe DST, please make sure to
uncheck this box.
Wireless Outdoor Sensor
The Wireless Outdoor Sensor sends temperature data to your Wireless Display,
accurate to within a tenth of one degree.
The Outdoor Temperature Sensor uses 2 x “AA”,
Alkaline batteries. To install and replace the
batteries, please follow the steps below:
1. Remove the battery compartment cover on
the back of the sensor.
2. Insert the batteries, observing the correct
polarity (see marking).
3. Replace the battery compartment cover on
the unit.
Press the “+” Key on your Wireless Display to show the outdoor temperature at
any time. The outdoor temperature will scroll on the bottom of the LCD.
Because the “+” key is used to toggle between time, date and temperature, when
you press the “+” key to view the outdoor temperature, you also switch to the
next view mode on the top segment of the LCD. Simply press the “+” key until
you are also viewing the desired mode: time, date or temperature.
Wireless Display Operation
This section will teach you how to use your Wireless Display once you have
completed online registration. There are 4 control Keys located on the front of the
Wireless Display: “SET”, “+”, “ALARM” and “MODE”. The following information is
divided into sections based on the function of each Key.
