iHome iH56 MP3 Docking Station User Manual



iH56 IB_4 inserts_0220_b.fh10 7/15/08 10:53 AM Page 5
iPod radio am/fm sleep
alm. on/off alm. set wake-to alm. reset
snooze/dimmer
volume
power off
AC Adaptor Jack ƹ
ƾ
Line in Jack
Ƽ Clock Adjust Button
Line Out Jack
ƺ
ƿ FM Antenna
AM Loop Antenna socket
Ƹ
ƽ DST Switch
DC 15V 1200mA
time zone clock adj.
DST
-1
+
1
line inline out
am antenna
2
Controls and Indicators
iH56 Display
Time Zone Button ƻ
Volume Wheel
Dock
iPod Button
¸
Set Wheel
Radio Button
AM/FM Select Button
µ Sleep Button
Alarm On/Off Button
Alarm Set Button
Wake-To Button
¹ Alarm Reset/Power Off Button
Snooze/Dimmer Button
Alarm Armed
Daylight Saving Time
Indicator
Battery Low Indicator
Time/Alarm Display
PM Indicator
Sleep Display
Wake To Indicator:
iPod, Radio, Buzzer,
Radio Frequency AM/FM Indicator
iPod Indicator
