Step 2. Install batteries cor-
rectly. Close the battery cabi-
net.
Step 3. Position your iPod
®
correctly.
Step 4. Connect iPod
®
with
3.5 mm audio cable. Turn on
the power for playback.
C
ongratulations on your purchase of the iBlaster
Express from Excalibur Electronics, Inc.
Your new portable audio system is designed
to deliver maximum enjoyment. Please take a few
moments to read this manual thoroughly.
It will explain the features and operation of your
unit and help ensure a trouble-free installation.
D
O NOT EXPOSE YOUR
I
B
LASTER
E
XPRESS TO RAIN OR MOISTURE
.
The legendary King Arthur
brandished a magic sword, Excalibur,
from which we take our company
name. With this unique weapon in his
hands, he could not be vanquished.
Although Excalibur Electronics can’t
claim the magical secrets of Merlin,
King Arthur’s court wizard, sometimes
our patented technology may make it
seem as if we could.
We make you think.
iPod
®
is a registered trademark of Apple Computer, Inc.
Layout of iBlaster Express
Figure 2
(See step two):
Battery Cover
Figure 1 (See step one):
iBlaster Express
Step 1. Unpack the unit care-
fully. Read this instruction sheet
completely. We recommend that
you save the carton and packing
materials to store the unit, in case
you ever need to return it for
service.
How to Use Setting up the iBlaster Xpress
Figure 3
(See step two):
Battery
Compartment
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired opera-
tion. NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable l interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna. • Increase the separation between the
equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Figure 4
(See step four):
3.5 mm audio
cable
• To reduce the risk of electric shock, do not expose this appliance to rain
or moisture. Potentially dangerous high voltages are present inside the
enclosure. Do not open cabinet. Refer servicing to qualified personnel only.
• For your safety, when disconnecting the DC power cord,
pull the power plug. Do not pull the cord by itself. Never handle the
DC power plug with wet hands, as this could cause fire or electric shock.
• Caution: If the plug or power supply cord needs to be replaced, please
ensure that it complies with the manufacturer’s recommendation.
• Do not attempt to repair the unit by yourself.
This should be done only by a qualifed service technician.
Warning
