21 CX609
Operations Common to Each Mode
● Setting the clock
2-1. Select “CLOCK”.
3-1. Press the [ ] button.
3-2. Press the [x] or [v] button to select the
hour or the minute.
3-3. Press the [w] or [z] button to set the
correct time.
∗ The clock is displayed in 12-hour format.
3-4. Press the [ ] button to store the time into
memory.
Note:
• You cannot set the clock when it is displayed
with only the ignition on. If you drain or remove
the car’s battery or take out this unit, the clock is
reset. While setting the clock, if another button or
operation is selected, the clock set mode is
canceled.
● Setting the contrast
You can adjust the display contrast to match the
angle of installation of the unit.
∗ The factory default setting is “10”.
(Adjustment level: 1 to 16)
2-1. Select “CONTRAST”.
3-1. Press the [w] or [z] button to adjust the
contrast.
● Displaying the settings
The number of indicator of this unit decreases,
you can see the state of current settings at any
operation mode.
2-1. Select “SETTINGS”.
3-1. Press the [w] or [z] button to display the
state of current settings.
∗ When the setting is selected, after 1 second
the current state will be displayed.
● Setting the button illumination
2-1. Select “COLOR”.
3-1. Press the [w] or [z] button to select the
color type.
• Setting COLOR SCAN mode
As selecting “COLOR SCAN”, the color
automatically changes.
∗ The factory default setting is “COLOR SCAN”.
∗ After 3 seconds the color changes to the other.
•
Setting USER mode
The factory default setting is “RED 8” (red),
“GREEN 8” (green), “BLUE 8” (blue).
As selecting “USER COLOR 1, 2, 3”, press the
[] button to enter the setting.
1. Press the [x] or [v] to select “RED”,
“GREEN” or “BLUE”.
2. Press the [w] or [z] button to select from 0
to 8.
3. Press and hold the [ ] button for 2 seconds
or longer to store the color in memory and
cancel the setting mode.
● Setting the anti-theft function
(CATS)
“CATS” is the acronym of “Clarion Anti-Theft
System”. When you set a PIN code (called as
“Personal Code”), a theft is prevented by
disabling the operation of the unit at the theft.
• Setting your Personal Code
2-1. Select “CODE”.
3-1. Press the [ ] button.
The set personal code screen appears.
4-1. Press the [DIRECT] buttons [1]-[6] to enter
your desired 4-digit Personal Code.
To change adjustment setting
1. Press and hold the [DISP] button (1 sec.)
to switch to the adjustment selection
display.
2. Press the [x] or [v] button to select
the “item name”.
“CLOCK” ↔ “CONTRAST” ↔
“SETTINGS” ↔ “COLOR” ↔ “CODE” ↔
“XM SRC” ↔ “SCRN SVR” ↔ “MESSAGE
INPUT” ↔ “SCROLL” ↔ “DIMMER” ↔
“BLINKLED” ↔ “A-CANCEL” ↔
“REAR/S-W” ↔ “SYSTEM CHECK”
3. Press the [w] or [z] button to select the
“desired setting value”.
∗ In the case of display blinking “ENT”, you
can press the [ ] button to adjust the
setting value.
∗ After completing settings, press the [DISP]
button to return to the previous mode.
For example: after 1 second,
CX609_ENG.book Page 21 Tuesday, January 13, 2009 10:52 AM
