1) Weather resistant design
2) Aluminum grilles, and brackets
3) hardware
4) abinet resists sun fade
) 14 AWG gold plated terminal posts
) 5.25" woofer with mica mix cone
) 1" soft dome tweeter
) 18dB /octave crossover network
) Tweeter protected by poly switch
Stainless steel
UV protected c
5
6
7
8
9
Model OS525
To set your OS525 on a shelf,
attach the rubber feet here
3
Specifications:
Frequency range:
Sensitivity:
Power Handling:
Drivers:
Impedance:
Finish:
Dimensions:
Weight:
45Hz - 20kHz ± 3dB
89dB (1W/1M)
100 Watts
1- 25mm soft dome tweeter
1- 5.25” woofer w/ 1” voice coil
6 ohms
ABS plastic
11”Hx6 ”Wx71/2”D
5.2 Lbs with bracket
3/4
Specifications subject to change without notice.
Installation:
h
h
h
h
h
The OS525 may be mounted vertically or horizontally.
The OS525’s case is weather resistant and made with UV
stabilized ABS. But for longest life, we recommend
placement in a protected area, such as under an eave.
We recommend wiring with AWG 16 or larger, stranded
wire.
For proper phasing, both speakers must be wired alike.
Connect red wire to red terminal on speakers and to red
or plus terminal on amplifier.
To control the volume of the speakers locally, use an
impedance matching volume control, such as the
Channel Vision VC-302.
