Kevlar is a registered trademark of Dupont.
B&W Loudspeakers Ltd. reserves the right to amend details of the specification without notice in line with technical developments.
Copyright © B&W Loudspeakers Ltd. Printed in England.
B&W Loudspeakers Ltd, Meadow Road, Worthing, BN11 2RX Tel: +44 (0) 1903 524801 Fax: +44 (0) 1903 524725
http://www.bwspeakers.com
I 8339 Issue 2
Description
Drive units
Frequency range
Frequency response
Dispersion
Sensitivity
Harmonic distortion
Nominal impedance
Crossover frequency
Power handling
Max. recommended cable impedance
Dimensions
Net Weight
CDMC
™
SE
2-way 4th-order vented-box magnetically shielded system
1x 165mm (6
1
⁄
2in) woven Kevlar
®
cone bass/midrange
1x 25mm (1in) alloy dome high-frequency
-6dB at 45Hz and 30kHz
50Hz – 20kHz ±3dB on reference axis
Within 2dB of response on reference axis
Horizontal: over 40° arc
Vertical: over 10° arc
90dB spl (2.83V, 1m)
2nd & 3rd harmonics < 1% 100Hz – 20kHz (90dB spl,1m)
8Ω (minimum 4.5Ω)
3kHz
30W – 120W continuous into 8Ω on unclipped programme
0.3Ω
Height: 260mm (10
1
⁄4in)
Width: 460mm (18
1
⁄
8in)
Depth: 274mm (10
3
⁄4in)
10.5kg (23.1lb)
