C10A: Frequency Response
C10A: Impedance
C10A : Fundamental vs 2nd & 3rd Harmonic (Raised 20dB)@ 1 Watt
C10A: Frequency Response Overlay at 0, 15, 30 & 45 degrees
Octave Bands Normalized to Zero On Axis
FREQUENCY (Hz)
FREQUENCY (Hz)
FREQUENCY (Hz)
ARCHITECT & ENGINEER SPECIFICATIONS
Unit shall be Atlas Sound 8" loudspeaker Model ______ or
loud speak er/trans form er combination Model ______ (utilizing line-
matching trans form er Model ______). It shall have a (10 oz.) ceramic
magnet and a seamless cone. Frequency response range shall be
_____________.
Sensitivity shall be _______. Voice coil shall be black anodized
aluminum to help dissipate heat, have an impedance of 8 Ohms and
a diameter of 1" (25mm). Transformer primary voltage shall be ____
with a frequency response range of _______. Insertion loss shall not
exceed ____.
