INMOTION IM510
M
OBILE AUDIO
Thank you for purchasing this Altec Lansing
product. For generations, Altec Lansing has
been first in audio innovation. Today, our line of
powered speakers has received more performance
awards than any other brand. In all kinds of
environments, in every price range, Altec Lansing
offers sound of distinction — giving even the most
demanding customers the audio enjoyment they
seek. Just listen to this!
Box Contents
• inMotion iM510 mobile speaker system
• Power supply
• Sansa docking adapters
• 3.5 mm stereo cable
• Protective carry bag
• User’s guide and quick connect instructions
Made for:
• Sansa C200 Series
• Sansa E200 Series
Placing the INMotion IM510
Position the inMotion iM510 on a level surface,
preferably close to you (within three feet).
Assembling the INMotion IM510
Open the inMotion iM510 docking bay by pushing
the button located on the speaker grille. Connect
the Sansa player to the inMotion iM510 by
plugging the docking bay connector into the Sansa
player port. If the Sansa player feels too loose
inside the docking bay, remove it, and use a
docking adapter (included) to reduce the depth of
the docking bay. The docking adapters can be
connected to the docking bay by inserting the
small tab on the back of the adapter into the
fitted space on the docking bay. The Sansa player
should fit snugly inside the adapter.
Note: Alternate audio sources — such as non-
dockable MP3 players, CD players, portable DVD
players, and laptops — can also be connected to
the inMotion iM510. For more information, see the
“Connecting to alternate audio source” section.
Power
Use one of the following two options to power
your inMotion iM510:
AC (Wall outlet) Power
Insert the barrel connector from the power supply
into the DC connector on the rear of the inMotion
iM510. After this connection is made, insert the
power supply into a wall outlet.
DC (Battery) Power
Install four AA batteries (not included) into the
battery compartments on the bottom of the
inMotion iM510 (two to each compartment). Make
sure the batteries are installed as illustrated in the
battery compartments.
Start Playing
1. Turn on your Sansa player.
2. Turn on the inMotion iM510 by pushing the
power button located on the top of the unit. A
blue LED will light around the button when the
power is on.
Note: To avoid hearing a popping sound when you
turn on your inMotion iM510, always turn on your
audio source first. When listening to FM radio,
remember to leave the headphones plugged in, as
they act as the antenna for the FM radio.
Power Off
Turn off the inMotion iM510 by pushing the power
button located on the top of the unit. The LED will
turn off.
Auto Shut-down (Standby)
During battery-only operation the inMotion iM510
automatically shuts down/goes into standby mode
if no audio is detected for three minutes. While
this mode reduces battery consumption, it does
not completely turn the inMotion iM510 off. To
maximize battery life when not using the inMotion
iM510, push the power button located on the top
of the unit. The LED will turn off.
NOTE: The Auto Shut-down (Standby) feature is
active during battery-only operation. If the AC wall
adapter is used, the inMotion iM510 will remain on
as long as the power switch is in the “On” position.
Syncing
The inMotion iM510 is equipped with a pass-
through feature that allows you to sync your Sansa
player with your computer while the Sansa player
is docked. To sync your Sansa player with your
computer, follow the steps below:
