Altec Lansing M602blk MP3 Docking Station User Manual


  Open as PDF
of 2

Works with all
iPod models
Bass Enhancement
Technology
COMPOSITE
VIDEO
Playback videos and
photos on your TV
AUX
Use other MP3, CD
and DVD players
Fill your living room with sound!
Wouldn’t it be great to plug your iPod into a speaker system? Well, now you can. Introducing the
Altec Lansing M602. It’s the complete package: Striking good looks, plus rich, clear sound from its four
custom-designed speakers. What’s more, the M602 is surprisingly affordable. Just place your iPod into
the M602’s built-in dock and enjoy.
R02
US08/07
M602
M602blk
M602
US08/07
M602blk
High-Denition Audio
Digital amplication delivers powerful sound from
a compact system.
Clean, Crisp Sound
Four specially engineered speakers smoothly deliver
a full spectrum of pure, distinct sound.
Surprisingly Deep Bass
XdB
™
bass-enhancement technology creates deep
bass without a subwoofer.
Wireless Remote and Built-in Controls
iPod and speaker functions (play, forward, back,
volume, bass, treble, and stand-by) are at your
ngertips. Just sit back and enjoy!
Easy to Use
Built-in universal dock allows data transfer and
recharges iPod.
Elegant, Wall-mountable Design
Looks great in your living room or mounted on wall.
Composite Video Output for iPod video
Enables you to play your iPod videos on most TVs
(cable not included.)
Universal MP3 Cradle
Allows you to place other MP3 players front and
center (cable included.)
Headphone Jack
For private listening.
SYSTEM SPECIFICATIONS
†
:
SOUND PRESSURE LEVEL (SPL): 100 dB
TOTAL CONTINUOUS POWER:
60 Watts RMS
SYSTEM RESPONSE:
60 Hz - 20 kHz (-10 dB)
SIGNAL TO NOISE RATIO:
@ 1 kHz input: > 70 dB
SPEAKERS:
DRIVERS: (per Satellite):
Two 3” full-range drivers and
two silkdome 1” tweeters.
DIMENSIONS: 14” (W) x 5.4” (D) x 8.2” (H)
(354 mm (W) x 137 mm (D) x 208 mm (H))
PACKAGING SPECIFICATIONS:
MASTER CARTON QUANTITY: 2
MASTER CARTON DIMENSIONS:
16.5” (W) x 15.7” (D) x 11.2” (H)
419 mm (W) x 399 mm (D) x 285 mm (H)
DISPLAY CARTON DIMENSIONS:
16” (W) x 7.6” (D) x 10.5” (H)
406 mm (W) x 193mm (D) x 266mm (H)
MASTER CARTON WEIGHT:
15.5 lbs. 7 kg
DISPLAY CARTON WEIGHT:
6.5 lbs. 3kg
Specications subject to change without notice.
1-year limited warranty (2 years in Europe and Asia;
see inside for details.)
† Power rating conforms to FTC Amplier Rule #16
C.F.R. Part 432.
© 2007 Plantronics, Inc. All rights reserved.
ALTEC, ALTEC LANSING, the Altec Lansing logo, and
swirl design are trademarks or registered trademarks
of Altec Lansing, a division of Plantronics, Inc.
Plantronics, the logo design and Sound Innovation
are trademarks or registered trademarks of
Plantronics, Inc.
iPod is a trademark of Apple, Inc., registered in
the U.S. and other countries.
All other trademarks appearing herein are the
property of their respective owners.
Designed by Altec Lansing in the USA.
Made in China.
HEADQUARTERS
535 Rte. 6 & 209. Milford, PA 18337-0277, USA
Tel: 800-ALTEC-88. 570-296-4434.
Fax: 570-296-6887
