Remote Control Operation (See Figure 7)
The remote control can perform most of the manual operations. For best performance aim the front part of the control towards the
infrared detector as shown in Figure 6. Below are listed the functions of the control.
POWER. Press this button to turn power on. The power indicator on the satellite will glow.
Press again to turn power off.
TREBLE. Press this button if it is desired to adjust the TREBLE level. The function indicator
above the TREBLE button on the satellite will glow. To increase/decrease volume, press the
up/down arrows on the VOL button. The volume level indicators will glow in ascending order
as volume is increased and will turn off in descending order as volume is decreased.
BASS. Press this button if it is desired to adjust the BASS level. The function indicator above
the BASS button on the satellite will glow. To increase/decrease volume, press the up/down
arrows on the VOL button. The volume level indicators will glow in ascending order as volume
is increased and will turn off in descending order as volume is decreased.
STEREO. Press this button to operate in the STEREO mode. The indicator above the
DOLBY button on. The satellite will be off in this mode.
MUTE. This function is only available when using the remote control. Press this button to mute
the sound. The volume level indicators will turn off. The power and function button indicators
remain on. Press this button again to restore sound.
Press any other function (except power) and sound will be restored.
CENTER. This function is only operational in the SURROUND mode. Press this button to adjust the volume level of the center
channel. The green function indicator above the BASS button on the satellite will flash on/off. Set the center level by using the
up/down volume control (VOL). The green volume indicators will glow in ascending order as volume is increased and will turn off
in descending order as volume is decreased.
SURR(SURROUND). This function is only operational in the surround mode. Press this button to adjust the volume level of the
SURROUND PRO-LOGIC mode. The green function indicator above the treble button on the satellite will flash on/off. Set the
surround level by using the up/down volume control (VOL). The green volume level indicators will glow in ascending order as
volume is increased and will turn off in descending order as volume is decreased.
DOLBY. The DOLBY button allows 2 modes of operation - STEREO or SURROUND.
(A)STEREO. When the function LED is off on the satellite, the unit is in the STEREO modes.
(B)SURROUND. When the amber function LED is on the satellite, the unit is in the surround PRO-LOGIC mode.
(C)DOLBY DIGITAL (AC3). When the function LED is green on the satellite, the unit is in the DOLBY DIGITAL (AC3) mode.
This function is selected automatically whenever a Dolby Digital surround signal is detected at the input. The automatic selection
will occur regardless of the mode of operation, STEREO or SURROUND.
Figure 7
