Technische Informationen
Architects and engineers
specications
VL 212
2 x 12“ / 1.4“
2-Way Professional
Speaker System
Wir weisen ausdrücklich darauf hin, dass bei
gehängten Lautsprecherboxen die einschlägigen
Sicherheitsbestimmungen zu beachten sind. Es
muss unbedingt qualizierte Fachberatung in
Anspruch genommen werden!
We expressly point out that the relevant safety
regulations must be observed for „ying“
loudspeaker systems. It is imperative that quali-
ed expert advice is sought.
Features:
. High-Power Multi-Functional 2-Way
Cabinet
. 800W 4 Ohms
. Rotatable CAD-optimized 90° x 45°
Constant Directivity Horn
. Switchable to Biamped Mode
. Neodymium 1.4“ ND6 Driver
. 2 x DND 12350 Neodymium Woofers
. Voice Coil Tracking Protection
Specifications
TYPE / NAME VL212
Order No. D 113 133
Cabinet Full-Range
Configuration Passive 2-Way
Switchable to biamped mode
Nominal impedance 4 Ohms
Rated power RMS 800 Watts
Program power 1600 Watts
Peak power 3200 Watts
SPL 2,83 V / 1m 2W / 4 Ohm 105 dB
Max. SPL 1m
(calculated with peak power)
137dB
Frequency range ( -10dB )
Full range 80Hz - 19kHz
Frequency range ( -10dB ) 50Hz - 19kHz
measured with H5000-RCM26 preset
Coverage angle 1 kHz -6dB 90° * 45°
Passive crossover frequency 1.5kHz
Active crossover frequency
1.5kHz 24dB/Oct. Linkwitz-Riley,
1,5kHz Linear-Phase FIR
Voice coil tracking protection Yes
Component HIGH Electro-Voice ND6-8 Neodymium
Order No. D361493
Component LOW 2 x DND 12350
Order No. D366559
Connectors Full-Range 1+, 1-
Wired through 2+, 2-
Connectors Biamped Lo 1+, 1- Hi 2+, 2-
Wired through 1+, 1-, 2+, 2-
Connector model Speakon 2x NL4 MPR
Dimensions (WxHxD) 385x1035x374mm
Net weight 34kg
Shipping weight 38.5kg
Enclosure material Birch plywood
Finish Black, 2-component paint
Grille Powder coated steel, acoustic foam
Handles
2
Warranty 36 Month
Optional Accessories
SH-VL212 Dust-Cover D113147
MB-VL212 D113153
TC-02 Truss clamp D112808
FB-VL212 Flying Bracket D113152
TC-TV Truss Clamp > TV Spigot D112941
PM-TV Pole Mount > TV Spigot D112942
