Pocketalker
®
PRO
Personal Amplifier • Model PKT C1
Pocketalker
®
PRO
Personal Amplifier • Model PKT C1
®
©2008, Williams Sound Corp. CAT
059F 1
NOTE: SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE!
Description:
The Pocketalker amplifies sound clearly and easily for better understanding. 100 hours of battery
life ensures long-lasting performance. Each Pocketalker includes a built-in sensitive microphone;
and for the TV listener: a TV listening extension cord. Use the Pocketalker with a variety of avail-
able earphones and headphones of your choice, or, for optimal performance, use it with a neck-
loop and a telecoil-equipped hearing aid. With the optional Telelink adapter, listeners can use the
Pocketalker to amplify telephone calls to a comfortable listening level.
Applications:
One-on-One Coversations • Television Listening • Listen in a Car • Small Groups and much more
Dimensions: 3-5/8" L x 2-3/8" W x 7/8" H
(92.1 mm x 60.3 mm x 22.2 mm)
Weight: 3.8 oz (110 g) with battery
Color and Material: Gray, shatter-proof polypropylene
Battery Type: 1.5V (AA) x 2, Alkaline (BAT 001) or recharge-
able AA NiMH (BAT 026)
Battery Life: 100 hours with BAT 001, 40 hours/charge with
BAT 026, 8 mA, nom. current drain
Microphone: Omnidirectional condenser, plug-mount-type,
3.5 mm mini phone plug
Earphone (3 Styles): Dynamic, wide-range “earbud” type, Samarium-
Cobalt magnet, 32 Ohm,
39" (1 m) cord, 3.5 mm mini phone plug (mono)
Controls: Volume: rotary on/off/volume control
Gain: Internal rotary maximum gain control
(screwdriver adjust)
20–45 dB acoustic gain w/EAR 013
Tone: Internal rotary tone control (screwdriver
adjust); +17 dB at 16 kHz at max. setting
Microphone Connector: 3.5 mm mini phone jack (mono)
Earphone Connector: 3.5 mm mini phone jack (mono)
Charging Jack: External side jack, 2.1 mm, Charger TFP 008 can
also be used as power supply
Frequency Response: 50 Hz–16 kHz, +1 –4 dB (electrical response)
Max. Distortion: .5% THD (electrical)
Max. Output Power: 125 mW into 16 Ohms (electrical)
Approvals: RoHS, WEEE
Warranty: 5 years, parts and labor*
NOTE: The POCKETALKER is not sold, advertised or
intended for use as a personal hearing aid.
Williams Sound recommends that any individual
experiencing hearing loss be examined by a
physician to determine the cause before using
amplification.
Pocketalker Pro:
*90 days on accessories.
Williams Sound
Pocketalker PRO Front View
(Model PKT PRO1-2)
Pocketalker PRO Top View
