Definition Install DS15i sub
Tannoyadoptsapolicyofcontinuousimprovementandproductspecificationissubjecttochange
DefinitionInstallDS15iSubdatafile//issue1.06//15.01.08
The Definition Install DS15i sub has been designed to underpin a Definition install theatre
or media room system with truly remarkable low frequency performance. Massively
constructed around 380mm (15.00”) professional drive unit, this subwoofer will produce the
ultimate soundtrack experience, with spectacular and thunderous bass, yet still be agile
enough to maintain finer musical detail with precision and speed.
This 76 litre direct radiating design is robustly constructed MDF enclosure, using 15mm
(0.62”) for the panels and 36mm (1.42”) for the front baffle. Extensive internal bracing
minimises panel resonance ensuring a tight and responsive bass performance. Capable of
achieving 36Hz and with a sensitivity of 96dB (1W = 2.83V for 8 Ohms), the DS15i sub will
deliver an SPL of 130dB peak. Recommended amplifier power is 600 – 1200W @ 8 Ohms.
Finished in rugged textured black paint, the enclosure is fitted with two binding posts, eight
M10 inserts and four rubber feet.
The DS15i sub is compact enough to bring class leading performance to a wide range of
installation applications; from media rooms to home theatre and boardrooms through to
high end marine interiors.
Product Description
• 1 x 380mm (15.00”) high power handling direct
radiating bass driver
• Immensely rugged 76 litre MDF enclosure is internally
braced, with 15mm (0.62") panels and a 36mm (1.37”)
front baffle
• Power handling 1200W programme
• Sensitivity 96dB (1W = 2.83V for 8 Ohms)
• Rated SPL 130dB peak
• 2 x binding post connectors, 8 x M10 inserts and 4 x
rubber feet
• Media rooms
• Home theatre
• Boardrooms
• High end marine interiors
Features
Applications
