DJS
™
4
Enclosure
SPECIFICATIONS
Frequency response:
58 Hz to 16 kHz
Usable low frequency limit
(-10 dB point):
42 Hz
Power handling:
500 W continuous
1000 W program
2000 W peak
Sound pressure level 1W @ 1M,
swept sine in anechoic environment:
99 dB
Maximum SPL:
125 dB continuous
134 dB peak
Horn pattern:
90 degrees horizontal by 45
degrees vertical
Transducer complement:
Two 15" Scorpion
®
Plus SP-15825
woofers, and one 2" RX
™
22 titanium
diaphragm compresion driver
tweeter
Box tuning frequency:
58 Hz
Electroacoustic crossover frequency:
2.8 kHz
Crossover type:
Internal passive psuedo-
three-way
Crossover slopes:
6 dB/oct. (1st order) low pass,
12 dB/oct. (2nd order) high pass
with constant directivity horn EQ
Nominal impedance:
4 Ohms
Minimum impedance:
3.4 Ohms
Input connections:
Two 1/4" phone jacks in parallel.
Weight:
93 lbs.
Dimensions:
48.875"H x 21"W x 17.75"D
Features:
• Dual 15" Scorpion Plus woofers
• RX22 compression driver
w/overload protection
• CH
®
-941 high frequency horn
• Lightweight enclosure
• Built-in pocket casters for easy
transport
• Specially voiced for DJ use
• Contemporary cosmetics
SPECS
PEAVEY ELECTRONICS
