SONOLINE SERIES
•
Column-type speakers with high-fidelity cone speakers in
vertical arrays offer high degree of directionality.
•
Cone speakers are resin-coated for high rain and water
resistance
•
Rugged metal cabinets make them ideal for outdoor use.
•
Perfect for a wide range of indoor and outdoor applications
including stadiums, parks, amusement parks, train platforms,
building roofs and gymnasiums.
Typical Directionality of a Sonoline Speaker
SONOLINE SPEAKER
WS-937N
SONOLINE SPEAKER
WS-938N
SONOLINE SPEAKER
WS-939N
Sonoline speakers
Horn speakers
SPECIFICATIONS
Model No. WS-937N WS-938N WS-939N
Rated Input 10 W 20 W 30 W
Input Impedance 1 kΩ, 2 kΩ 500 Ω, 1 kΩ 320 Ω, 670 Ω
Frequency Response 170 ~ 10,000 Hz 170 ~ 10,000 Hz 170 ~ 10,000 Hz
Sound Pressure Level More than 93 dB SPL, 1W, 1m More than 95 dB SPL, 1 W, 1 m More than 97 dB SPL, 1 W, 1 m
Speaker Used 12 cm cone speaker 2 units 12 cm cone speaker 4 units 12 cm cone speaker 6 units
Dimensions 167 (W) x 335 (H) x 141 (D) mm 167 (W) x 580 (H) x 141 (D) mm 167 (W) x 825 (H) x 141 (D) mm
Weight (Approx.) 4.1 kg (including mounting bracket) 6.1 kg (including mounting bracket) 8.6 kg (including mounting bracket)
Finish Case Munsell N7 Gray Color Metallic Painting Munsell N7 Gray Color Metallic Painting Munsell N7 Gray Color Metallic Painting
Front Panel Punched Panel with Black Semi-grossy Painting Punched Panel with Black Semi-grossy Painting Punched Panel with Black Semi-grossy Painting
Appearance
84
167
50
141
25
580
635
84
167
50
141
25390
335
167
84
141
50
25
825
880
WS-937N WS-938N WS-939N
New
New
New
unit: mm
