Listen Technologies LS-15-216 Portable Radio User Manual



Don't miss a single sound.
updated 07.25.05 Listen
®
and the Listen logo are registered trademarks of Listen Technologies Corporation
Listen Technologies Corporation
8535 South 700 West, Suite A
Sandy, UT 84070-2515 U.S.A.
Phone: 1.801.233.8992 or 1.800.330.0891
Fax: 1.801.233.8995
Email: info@ListenTech.com
Wireless Distribution FM System
Specify Part
Number
LS-15-216
Qty Item
1 LT-800 Stationary FM Transmitter
1 LA-326 LT-800/LR-100 Rack Mounting Kit
1 LR-100 Stationary FM Receiver/Power Amplifier
2 LA-107 Ground Plane Remote Antenna
Accessories
The Wireless Distribution FM System is a perfect option for events that don't have
existing hard-wire infrastructure available for audio distribution. Available in 216 MHz
only.
LA-113 RG-8 50 Ohm Low-Loss
Coaxial Cable
Recommended for coax runs
greater than 100 ft. (30.5 m) at
72 MHz or 50 ft. (156 m) at 216
MHz. Minimum order of 20 ft.
(6.1 m). For use with FM products
only.
LA-128 RG-8 BNC Connector
BNC connectgor for RG-8
coaxial cable. Crimp style.
Order LA-114 to have 2 of
these connectors installed
on RG-8 cable (LA-113).
LA-114 Installtion of BNC
Connector (2)
Service charge for Liesten to
terminate your coaxial
cable. Purchase coax cable
and connectors separately.
