DETAILED SET-UP GUIDE
I. BATTERY INSTALLATION
A. REMOTE CONTROL SENDER
1. Remove the mounting bracket. The
bracket snaps on and off easily.
2. Remove the battery cover, by sliding the
cover down.
3. Observing the correct polarity install 2
AA batteries. The batteries will fit tightly
(to avoid start-up problems make sure
they do not spring free).
4. Replace the battery cover by sliding upwards. Be sure battery
cover is on securely.
B. WEATHER STATION
1. Remove the battery cover. To do
this, insert a solid object in the space
provided at the lower-central position
of the battery cover, then push up and
pull out on the battery cover.
2. Observe the correct polarity, and
install 2 AA batteries.
3. Replace the battery cover.
Note:
Immediately after the batteries have been installed, the
LCD (Liquid Crystal Display) will flash, and a tone will sound.
Within a few seconds the indoor temperature, indoor relative
humidity, and the weather icons (sun and clouds) will be
displayed. If not, remove batteries for 10 seconds and reinstall. If
the outdoor temperature is not displayed within four minutes,
remove batteries from both units, wait 10 seconds, and reinstall
making sure to install batteries into the sensor first. The time will
show -:-- and start searching for the signal. If it successfully
receives the time signal (usually at night), it will display the
Battery
Cover
Battery
Cover
