Electro-Voice Sx100+ Portable Speaker User Manual



Key Features:
Compact, Ergonomic Size
Integral Monitor Stand
Ring-Mode Decoupling (RMD
TM
)
Pure Titanium Compression Driver
65° x 65° Constant Coverage Horn
High Efficiency, High Output
Molded-in Pole Mount, Rigging Points
Sx100+
Compact Portable Sound
Reinforcement Speaker for
Live Sound, Speech, Playback, DJ,
A/V, Institutional Venues
General Description:
The Electro-Voice ® Sx100+ is a 200-watt, 12-inch two-way,
high efficiency, constant-directivity portable speaker system.
Through the extensive use of computer-aided design and
modeling, Electro-Voice engineers have developed a state-
of-the-art professional loudspeaker system. Its performance
and physical design make it perfect for many applications
requiring quality sound in portable and fixed environments.
The high-frequency section of the Sx100+ utilizes a molded-
in, 65° x 65° constant-directivity horn. This unique pattern
contributes to high intelligibility, vocals sound natural yet “cut
through” in reverberant, noisy rooms. Coverage pattern is
uniform, sound quality off-axis is very well maintained, even
at 45° off axis (a 90° total coverage angle).
The horn’s unique, Varipath
TM
throat geometry helps driver
output to the corners of the room, areas which are not
described in the usual specifications of horizontal and vertical
coverage angles. This results in more uniform coverage
throughout, even to those parts of the audience that typically
do not receive the strongest coverage.
The Sx100+’s high-frequency horn is driven by the DH3, a
one-inch-throat, wide-bandwidth, titanium-diaphragm driver
using a unique, convex-drive TimePath
TM
phasing plug
structure (U.S. Patent #4,525,604) for smooth and extended
high-frequency response.
Technical Specifications:
:)Bd01-(esnopseR.qerFzHk52-zH06
:ytivitisneSBd89
:LPSxaMBd721
:ecnadepmI.niMsmho6.5,lanimoNsmho8
:egarevoClatnoziro56
:egarevoClacitre56
:gnildnaHrewoPkaePW008,suounitnoCW002
:recudsnarTFL)mm003("21
:recudsnarTFHrevirD.pmoC3HDtixe)mm52("1
:srotcennoCnokaepSkirtueN
®
:lairetaMerusolcnEremylopoC
:ellirGleetSdetaoCredwoP
:)DxWxH(miD"3.21x"9.61x"1.32
)mm213x924x685(
:thgieWteN)gk5.41(sbl23
:thgieWgnippihS)gk9.51(sbl53
