Blackmore BDP-330 Portable DVD Player User Manual



Note:
1. First remove the two screws that lock the unit core, then attach the brackets on
both sides of unit with screws (M4x6), last install the unit with screws (M5x25).
2. When mounting the unit, you can slide the screw (M5x25) to left side or right side
to position the player.
Note:
INSTALLATIONINSTALLATION
66
Cautio
ns
1. Make sure to ground the unit to a negative 12V DC power supply
2.When replacing a fuse, only use a new one with the prescribed rating. Using a fuse with wrong
rating may cause the unit to malfunction.
3.To prevent short circuits when replacing a fuse, first disconnect the wiring harness.
4.Do not use any screws except for the ones provided. Using improper screws may damage the unit.
5.If you experience problems during installation, consult your supplier.
!
ALL INSTALLATIONS ARE DIFFERENT. IF YOU ARE NOT FAMILURE WITH THIS TYPE
OF EQUIPMENT OR INSTALLATION PLEASE CONSULT YOUR BLACKMORE MOBILE DEALER
FOR INSTALLATION OR ADVISE.
