Blackmore BDP-330 Portable DVD Player User Manual



SETUPSETUP
INITIAL SETUP
SETUP MENU ---MENU PAGE
1.Press SETUP in the stop mode.
(Press the stop button twice to ensure
the player is in the STOP mode.)
2.The initial SETUP menu is displayed.
3.Select the preferred item by using the
/ buttons.
4.Press ENTER button to select.
a. GENERAL SETUP
This setup page includes all the
items for TV display & audio output
features. For detaisl p l e a s e r e fer to
the GENERAL SETUP MENU.
b. SPEAKER SETUP
This is to activate the audio output
from DOLBY AC3 5.1 DOWNMIX
to 2 channel mode. Please refer to
SPEAKER SETUP MENU.
c. AUDIO SETUP
This setup page includes all the
items for AUDIO. Please refer to
AUDIO SETUP MENU.
d. PREFERENCE SETUP
This setup page includes all the
configuration of support features.
For details please refer to the
PREFERENCES SETUP MENU.
INITIAL SETUP
a. GENERAL SETUP
b. SPEAKER SETUP
c. AUDIO SETUP
d. PREFERENCE SETUP
GENERAL SETUP
SPEAKER SEUP
AUDIO SETUP
EXIT SETUP
PREFERENCES
GENERAL SETUP
--- GENERAL PAGE ---
TV display setup
This is to select the appropriate TV
aspect (4:3 or 16:9) according to the
connected Monitor.
Normal/PS (For 4:3 TV)
Played back in the PAN & SCAN style.
(If connected to wide-screen TV, the left
and right edges are cut off.)
Normal/LB (For 4:3 TV)
Played back in letterbox style.
(If connected to wide-screen TV, black
bands appear at top and bottom of the
screen.)
Wide (For 16:9 TV)
Select when a wide-screen TV set is
connected.
GENERAL SETUP
TV display setup
Normal/PS
Normal/LB
Wide
MAIN PAGE
WIDE
PIC MODE
ANGLE MARK
OSD LANG
CAPTIONS
SCR SAVER
NORMAL/PS
NORMAL/LB
Video
Material
TV Screen
4:3
Wide(16:9)
Normal
Pan Scan
Letter-box
1313
TV DISPLAY
FM FREQUENCY
