VIRTUBE VT100FXH/VT100FX/VT250FX/VT50FX
Specications 9
Specications 5.
VT100FXH VT100FX VT250FX VT50FX
AUDIO INPUTS
INPUT 1/4" TS, RF ltered
Input impedance approx. 1 MΩ, unbalanced
FX RETURN 1/4" TS 2 x 1/4" TS 1/4" TS
Input impedance approx. 33 kΩ, unbalanced
CD IN 1/4" TRS
Input impedance approx. 5.6 kΩ, unbalanced
AUDIO OUTPUTS
FX SEND 1/4" TS
Output impedance approx. 8.2, kΩ unbalanced approx. 5.6, kΩ unbalanced
LINE OUT/PHONES 1/4" TRS, unbalanced
Output level max. +16 dBV/100 Ω
LOUDSPEAKER OUTPUTS
Type 2 x 1/4" 1/4" 2 x 1/4" 1/4"
Min. load impedance 4 Ω 2 x 8 Ω 8 Ω
AMPLIFIER
Peak power 100 Watts / 4 Ω 2 x 50 Watts / 8 Ω 60 Watts / 8 Ω
DIGITAL SIGNAL PROCESSING
Converter 24-bit, sigma-delta
Sample rate 40 kHz
LOUDSPEAKER
Size - 12'' 2 x 12'' 12''
Model
- BUGERA Vintage Guitar Series
- 12G70J4 2 x 12G50J8 12G50J8
Impedance - 4 Ω 2 x 8 Ω 8 Ω
Continuous power
(IEC268-5)
- 70 Watts 2 x 50 Watts 50 Watts
Peak power - 280 Watts 2 x 200 Watts 200 Watts
POWER SUPPLY
Power consumption max. 180 Watts max. 180 Watts max. 180 Watts max. 90 Watts
Fuse 100 V~, 50/60 Hz T 2.5 A H 250 V T 2.5 A H 250 V T 3.15 A H 250 V T 1.6 A H 250 V
120 V~, 50/60 Hz T 2.5 A H 250 V T 2.5 A H 250 V T 2.5 A H 250 V T 1.25 A H 250 V
220 - 230 V~, 50/60 Hz T 1.0 A H 250 V T 1.0 A H 250 V T 1.25 A H 250 V T 630 mA H 250 V
Mains connection Standard IEC receptacle
DIMENSIONS/WEIGHT
Dimensions
(H x W x D)
245 x 580 x 270 mm 550 x 580 x 275 mm 520 x 670 x 275 mm 520 x 515 x 275 mm
9.7 x 22.8 x 10.6" 21.6 x 22.8 x 10.9" 20.5 x 26.3 x 10.8" 20.5 x 20.3 x 10.8"
Weight 27.3 lbs (12.4kg) 44 lbs (20 kg) 48.4 lbs (22 kg) 35.6 lbs (16.2 kg)
BEHRINGER is constantly striving to maintain the highest professional standards. As a result of these efforts, modications may be made from time to time to existing products
without prior notice. Specications and appearance may differ from those listed or illustrated.
