B&C Speakers ME10 Portable Speaker User Manual

LF Drivers LF Nd Drivers Coaxials HF Drivers Horns
1” throat entry
90° x 60° nominal coverage
Hyperbolic cosine flare
Very good loading down to 1.5 kHz
Throat Diameter (1) 25 mm (1 in)
Nominal Coverage Horizontal 90°
Nominal Coverage Vertical 60°
Cutoff Frequency 1.5 kHz
Material ABS
Dimensions 130.5x130.5x90 mm
(5.1x5.1x3.5 in)
Mounting and Shipping Info
Four 6 mm (0.25 in) holes 90°
on 76 mm (3 in) diameter
Baffle Cutout Dimensions 104x104 mm (4.1x4.1 in)
Net Weight (1 unit) 0.15 kg (0.33 lb)
Shipping Weight (20 unit) 6 kg (13.2 lb)
Shipping Box (20 unit) 540x350x390 mm
(21.2x13.8x15.3 in)
Horn mounted on B&C DE10 compression driver
