Stand-mount/Bookshelf loudspeaker system
The DM110i is a 2-way vented box standmount/bookshelf system with high power handling
Super sensitive, with high acoustical output yet affordable.
Modal analysis techniques revealed a simple bonding technique of corner joints could improve
rigidity and reduce coloration.
New thinking on crossover design has also led to the provision of higher safe power handling
and fuse protection overload.
The driver chassis have non-magnetised castings for all the bass midrange units ensuring resonant
free high-level sound of the highest amplitude.
B&W Loudspeakers Ltd reserves the right to amend details of the specifications without notice in line with technical developments. E & OE. All trademarks acknowledged.
1 x 26mm high-frequency driver with
dome/coil construction of special
1 x 200mm nominal piston dia and
26mm high temperature voice coil with
critically impregnated composite short
± 3dB 70Hz to 20kHz
90dB (2.83V, 1m)
10W – 75W
Height: 490mm Width: 260mm
American Walnut or Black Ash vinyl
