Bowers & Wilkins CDM 1NT Portable Speaker User Manual

Stand-mount/Bookshelf loudspeaker system
Product Summary
The CDM 1NT builds on the success of the CDM1 SE product, which received countless
awards for sonic excellence, build quality and overall performance. The cabinet is
exquisitely finished in real wood veneers, and is skillfully fashioned to produce the graceful
curves and contours that actually seek to reduce resonances and enhance clarity of sound.
Technical highlights
Tweeter on top: B&W's Tweeter on top technology ensures that the sound
remains focused and time-sensitive and that the stereo-image is presented with
unparalleled three dimensional accuracy.
Kevlar®: B&W developed and patented the method of using Kevlar® for
loudspeaker cones to reduce unwanted standing waves. DuPont originally
created Kevlar® for use in bulletproof vests.
Flowport™: Golf ball aerodynamics theory points the way towards lower
distortion reflex ports. Dimples improve the way the air flows over the surface of
any object. In the case of reflex ports, they offer a significant improvement over
simply flaring the port ends in reducing air flow turbulence at each end of the
port; so you get less chuffing noise and less compression at high sound levels.
B&W Loudspeakers Ltd reserves the right to amend details of the specifications without notice in line with technical developments. E & OE. All trademarks acknowledged.
Drive units
Frequency response
Nominal impedance
2-way vented-box system
1 x 25mm alloy dome high-frequency
1 x 165mm woven Kevlar® cone
60Hz – 20kHz ± 3dB on reference
88dB spl (2.83V, 1m)
8(min 4.6)
Power handling
50W - 120W into 8 ohm on unclipped
Height: 393mm Width: 220mm
Depth: 290mm
Cabinet: Real wood veneers, Black Ash,
Cherrywood, Red Stained Cherrywood
Grilles: Black cloth
