1601 JACK MCKAY BLVD. / ENNIS, TEXAS 75119 U.S.A.
TELEPHONE: (800) 876-3333 / FAX (800) 765-3435
AtlasSound.com
2.9
Specifications subject to change without notice
© 2002 Atlas Sound Printed in U.S.A. 000202 SL1-1193
One
STRATEGY SERIES
™
SURFACE MOUNT LOUDSPEAKERS
SM82-B
SM82-W
SM82-W
SM82-B
SPECIFICATIONS
MODEL: SM82(-B)(-W)
POWER RATING
(RMS): 150 W
IMPEDANCE, NOMINAL: 8 Ohm
FREQUENCY RESPONSE
(+/- 3dB): 65Hz to 20kHz
SENSITIVITY
(1W/1M): 92dB
WOOFER SIZE: 8"
CONE: HYCONE Treated Paper
SURROUND: Treated Cloth
MAGNET: 30 oz
COMPRESSION DRIVER
SIZE: 1" (25mm)
DIAPHRAM
MATERIAL: Titanium
MAGNET: 13.32 oz
CROSSOVER FREQUENCY: 2.5 kHz
CROSSOVER TYPE: 1st Order Low Pass,
2nd Order High Pass
DIMENSIONS: 16
1
⁄
2"H x 9
1
⁄
16"W x 8
7
⁄
16"D
41.9cm x 23.0cm x 21.49cm
WEIGHT
(WITH BRACKET): 16.32 lbs. (7.4kg)
Model SM82T (70.7/100V) Version also available, see SL1-1194
FEATURES:
• Compact, 2-way loudspeaker systems for exceptional performance
in music and sound reinforcement systems
• Weather-resistant construction for year-round indoor or outdoor use:
UV-resistant, talc, impregnated polypropylene injection molded enclosure,
powder coated aluminum grilles and all brass hardware inserts
• Conforms to 100HR salt spray test per ASTM B117
• Color matched heavy-duty zinc chromate plated and powder coated
"C" bracket (included)
• Highly efficient 8" HYCONE™ treated woofer
• 1" exit titanium high frequency compression driver
• Atlas Sound TRX WAVEGUIDE™– A constant directivity style
high frequency wave guide system provides accurate, even high
frequency coverage
• Atlas Sound POLYGUARD™ high frequency circuit diverts damaging
transient signals to protect the tweeter
• All
1
⁄4"-20 hardware Inserts allow easy integration of "off-the-shelf"
security hardware
• OMNIMOUNT™ 75 series compatible
• Available in black or white
• Five-year warranty
APPLICATIONS:
Use surface-mount Atlas Sound SM Series loudspeaker systems for
commercial, professional and residential applications or where high-
fidelity sound and weather-resistance is desired. Full-range frequency
response makes these systems ideal for indoor and outdoor installation,
in monaural and stereo foreground or background music systems,
and for applications in boutiques/shops, restaurants/cafes, leisure,
recreation/sports centers and houses of worship. Multi-position,
C-shaped mounting bracket and rugged construction provide optimum
installation flexibility and assurance of long-term service.
GENERAL DESCRIPTION:
Environment-resistant SM82 Series loudspeaker systems offer quality
sound reproduction and contemporary styling in a compact enclosure.
System components consist of a highly efficient woofer section and
1" exit compression driver frequency device. Vocal and musical clarity
is optimized by the mathematically conceived, advanced design of
the Atlas Sound TRX Control WaveGuide high frequency director.
This design provides smooth, even sound coverage (65˚H x 65˚V).
The high frequency section is symmetrical, for equal coverage in both
vertical and horizontal cabinet mounting positions. High frequency
component protection is provided by the Atlas Sound PolyGuard protec-
tion circuit. Both drivers feature low-flux-leakage designs enabling the
speaker to be used in close proximity to video monitors. For critical
video monitoring applications, a minimum distance of 18 inches from
the edge of the loudspeaker to the edge of the CRT is recommended.
To withstand the harshest environments, the new Strategy Series
SM82 surface mount loudspeakers are constructed of weather
resistant materials: UV-resistant, talc impregnated, polypropylene
injection molded cabinets; HYCONE treated woofer cones; powder
coated aluminum grilles and all brass hardware. The Strategy Series
speaker systems include a versatile yet simple C-bracket designed to
provide easy vertical or horizontal installation on just about any surface.
