4-3/16"
6-5/8"
8"
Specifications subject to change without notice
© 2001 Atlas Sound LP Printed in U.S.A. 000501 SL2-1484
141
TWO
1601 JACK MCKAY BLVD. / ENNIS, TEXAS 75119 U.S.A. / TELEPHONE: (800) 876-3333 / FAX (800) 765-3435
25-WATT
CONCEALED-MOUNTING LOUDSPEAKER
MO-2
MO-2
TECHNICAL SPECIFICATIONS
Models: MO-2
Power Rating: 25 watts
Frequency Response: 400-15,000 Hz (nominal)
550-13,500 Hz (+5dB)
Sensitivity (SPL): 122dB at 25 watts (peak)
115dB at 25 watts/1 meter (avg) 550-13,500 Hz
108dB at 1 watt/1 meter (avg) 550-13,500 Hz
Dispersion Angle: 85° (-6dB, 2 kHz octave band)
Impedance: 8 ohms
Dimensions: 6
5
⁄
8
"W x 8"H x 4
3
⁄
16
"D (365 x 210 x 327mm)
Weight: 5 lbs. (2.3kgs)
Finish: Grey baked epoxy
FEATURES
• Heavy-Duty Loudspeaker with Optimum Voice and Signal Intelligibility
for Industrial, Marine, Military and Vehicular Applications
• Impact and Environment-Resistant Construction for Dependable
Indoor/Outdoor Use
• U.S.-Made Compression Driver Assures High Reliability
• Specifically Designed for Surface or Concealed Mounting
APPLICATIONS
Utilize loudspeaker Model MO-2 for signal transmission in inter-
com/talkback, electro-acoustic warning, CB, transceiver and public ad-
dress systems in marine, vehicular, military, service and processing fa-
cilities. Unit is ideal for concealed mounting or where minimum aero-
dynamic obstruction is desired. Model MO-2 is engineered to with-
stand demanding environmental elements as produced in mining,
steel and chemical processing, oil exploration, power generation and
railroad facilities. Note: for explosion-proof loudspeakers refer to
HLE/MLE Series, SL2-1421.
GENERAL DESCRIPTION
Compact, double re-entrant unit with platform base is constructed of
heavy-gauge, die cast aluminum to minimize potential damage caused
by vibration, shock, impact, dust, wide temperature variations, high hu-
midity, salt water and other rigorous conditions. Its integral compres-
sion driver provides optimum efficiency and signal intelligibility. Model
MO-2 also assures superior sensitivity when used as a microphone for
two-way intercommunication. All exposed parts are finished in grey
epoxy. Dimensions: 6
5
⁄8"W x 8"H x 4
3
⁄16"D. (168 x 203 x 106mm).
Weight: 5 lbs. (2.3 kg.)
ARCHITECT AND ENGINEER SPECIFICATIONS
Concealed-mounting loudspeaker shall be environment-resistant
Atlas Sound Model MO-2 with power capability of 25 watts.
Frequency response shall be 400-15000Hz (Nominal), 550-13,500
Hz (+5dB). Sound pressure level shall be 115dB (25W/1M), 108dB
(1W/1M). Dispersion angle shall be 85°. Voice coil impedance shall
be 8 ohms. Loudspeaker shall provide superior sensitivity when
used as a microphone for two-way intercommunication. Unit shall
have a platform base constructed of heavy-gauge, die cast alu-
minum. Construction shall be die cast aluminum with all exposed
parts finished in grey baked epoxy.
