MODEL XMC90 OWNER’S MANUAL
VERSION V 0.0 Page 14 of 20
7.1 Beeper Speaker
This speaker provides beeper tone alarm audio output.
7.2 DC IN Jack
This jack connects to the 15 V DC output of the AC/DC adapter supplied with the radio.
7.3 AUX IN Jack
This RCA (red/white) stereo type jack accepts an external audio input from an optional DVD player, video game
console, etc.
7.4 Headphone Jack
This 3.5mm jack provides an audio output to external stereo headphones.
7.5 XM Antenna Connector
This jack provides input connection for the external SMB type XM antenna which is sold separately.
7.6 AM Antenna Connector
This jack provides input 3.5mm connection for a stereo headphone type AM loop antenna supplied with the unit.
7.7 FM Antenna Jack
This connector provides input for a 75Ω F-connector type FM antenna supplied with the unit.
7.8 Port Tube
This port on the bottom of the unit provides a heat exhaust for the speaker. DO NOT BLOCK THIS PORT.
