MODEL XMC90 OWNER’S MANUAL
VERSION V 0.0 Page 10 of 20
3.1 Using the iPod Dock
1. Swing up the protective cover door to access the iPod/XM receiver system connector bay.
2. Choose the compatible adapter/holder for your iPod model and install it in the bay.
Note: The XMC90 is supplied with an iPod adapter for installation in the iPod bay. Most iPods come with their own
(original) adapters which can also be used if necessary.
3. Install the iPod carefully onto the iPod connector and press down lightly until the iPod bottoms into the recess. The
iPod will be inclined slightly toward the rear of the XMC90.
4. Press the MODE button to highlight the current mode and rotate the scroll wheel until iPod is highlighted; then press
select and observe the following display screens:
iPod Boot-up Screen iPod With Clock
5. Press Scroll Wheel twice; a beep sounds and the iPod menu can now be accessed using the Scroll Wheel.
P/N: CNP2000
